Basic equipment:

• 1-Axis NC swivel head, swivel radius 300 mm, swivel angle +/- 105°
• Motor spindle 15,000 1/min., 30 kW, 191 Nm
• Tool holder HSK A63
• 48 tool places
  tool Ø max. 135 mm, tool length
  max. 460 mm, tool weight max. 10 kg
• NC rotary table with face plate  Ø 800 mm, integrated into the machine table, rotation speed max. 25 1/min., with worm drive
• Rapid traverse 30 m/min in all axes
• Working area, fully enclosed, with roof, ergonomic machine front in curved design for optimal accessibility of the machine interior
• Internal coolant supply 20 bar / tank capacity 900 l
• 3D radio touch probe

Options - if the production status of the machine allows:

• Preparation additional tool magazine
• Additional tool magazine with 220 places
• Additional control panel
• Mechanical mist collector CMC 1500 J-SP
• Partition wall for double work station system for Y-axis up to 800 mm
• Position of partition wall =   200 mm
• Tool breaking control and measuring of tool length
• Tactile tool breaking control
• RTS tool setter system for measuring, checking and tool breakage control of cutting tools in the machine
• Collision monitoring UT-Tec
