Basic equipment:

• NC swivel head, continuously swivelling by +/- 105°
• Motor spindle 20 - 12.000 1/min, 44 kW, 30 Nm
• Tool holder HSK 100
• 60 tool places + additional magazine 75 places
• NC rotary table
  - with face plate Ø 630 mm I 400 1/min
  - with face plate Ø 1.450 mm with
  worm drive, incl. special covering for
  swivel circle 1,500 mm, integrated into the machine table
• Clamping pallet for rotary table
• 38 zero-point clamping systems Unilock ESM 138, integrated into the machine table
• 16 zero-point clamping systems in face plate Ø 1,450 mm
• 4 zero-point clamping systems in face plate Ø 630 mm
• Electronic handwheel
• Working area, fully enclosed, with roof
• Internal coolant supply 20 bar / tank capacity 900 l
• Lateral loading door for long parts
• 3D radio touch probe


New parts of the machine:

• All drive motors
• Ball screw in X-, Y-  and Z-axis
• Additional control panel
• Linear roller guides in X- , Y- and Z-axis
• Internal coolant supply pumps
• Hydraulic unit
• Central lubrication
• Coolant unit for control cabinet
• Motor spindle (exchange spindle)
• All cables and hoses
• All parts, having being defective, upon inspection
