Basic equipment:

• NC swivel head, continuously swivelling by +/- 105°
• Motor spindle 20-12.000 1/min., 44 kW, 280 Nm
• Tool holder HSK 100
• 40 tool places + additional magazine 60 places
• NC rotary table
  with face plate Ø 630 mm I 1,000 1/min,
  milling max.: 850 kg, turning max.: 850 kg
  including direct measuring system and CNC-Axis with
  servo drive, precision: +/- 4,
  integrated into the machine table
• 6-fold rotary distributor for rotary table
• Electronic handwheel
• Temperature control for the coolant unit,
  constant temperature +/- 2 degree,
  including 900 l coolant container
• Internal coolant supply 70 bar / tank capacity 900 l
• 3D probe with wireless signal transmission
• Oil mist extraction unit
• Partition wall for double work station system for Y-axis up to 800 mm
• Tool breaking control and measuring of tool length, design with short laser fork and air nozzle,
  including tool measuring software

New parts of the machine:

• All linear guides and linear slides
• Ball screws
• Cooler
• Hoses and diverse small parts
• All parts, having been defective, upon inspection
