Two work areas. Loading and unloading during machining
Reduction of the piece time by 50%
Tool change directly above the workpiece
Work area change in approx. 4 seconds
Ideal concept for manual and automatic loading

With two spindles – to reduce the unit cost
The MATEC 30LD belongs to the MODULAR SERIES.
The proven design principles of the MATEC modular
system guarantee the ideal configuration for almost any
production methods. Customer requirements and
machining centre can thus be optimally matched.
The basic machine with double spindle and two work
areas has already been designed for series production.
Furthermore, it can be expanded by various optional
equipment.

Variants of the basic machine

• Motor spindles, increased power and speed.
• Extension of the spindle distance from 400 to 550 mm.
• Second Z-axis for compensation of different workpiece lengths.

Variants of the machine table assembly group

• Standard fixed table, optionally with table lowering by 100 mm.
• Prepared for 1-axis or 2-axis double rotary tables for multi-sided machining.
• Version without fixed table, however, with mounting brackets for the installation of various equipment.
• Swivelling machine table in bridge design

Pendulum machining with two work areas. Version without fi xed table,
however, with mounting brackets for the installation of various equipment for high workpieces

Rotary table – swivel bridge – counter bearing:
Clamping capacity for 16 workpieces
