MATEC 40HVC - 5-Axis machining centres

Performance class HSK100

The standard machine for complex 5-side machining

  • High stability and precision
  • 1 Short delivery times

Standard equipment in all machines

  • 1-Axis CNC swivel head, infinitely variable
  • Heidenhain TNC 640 control
  • Tool holder HSK100
  • Tool magazine 40 places
  • CNC rotary table Ø 800 / 1,150 mm
  • Work area full enclosure with roof
  • Direct path measuring system in X-, Y- and Z-axis
  • Chip conveyor

Additional options

  • Siemens 840D sl
  • Tool holder SK50
  • Tool magazine extension to 172places
  • High-pressure coolant unit
  • Rotary tables mounted for shaft machining
  • Work area partition wall

Motor spindle
Speed: 8,000 1/min
Power max: 42 kW
Torque max: 265 Nm
Tool holder: HSK100 | SK50

Swivel head
Swivel angle: ± 105° degrees infinitely variable
Direct path measuring
system: ± 3“
Clamping forces: 2,400 Nm unclamped
4,200 Nm clamped

Integrated CNC rotary table
For Y-axis 825 mm: Ø 800 mm
For Y-axis 1,125 mm: Ø 1,150 mm
